全自動三折背心 / 垃圾袋製袋機+自動包裝系統 / STB-28-3F-OS+FAP
產品特色
Computer control over the entire process
From film roll to final bag, one process flow
Servo motor, as standard attachment, makes it easy to adjust the bag length and the production speed
Automatically stop when...
/ running out of film
/ color scanning error
Magnetic roller rotating perforation
產品規格
| MODEL | STB-28-3F-OS+FAP |
|---|---|
| Production Size |
Length : 500 mm ~ 1000 mm Width : 350 mm ~ 660 mm Thickness : 12 ~ 35 um |
| Power |
220 V, 3 Phases, 50 / 60 HZ, 30 KVA |
| Production Speed |
50 ~ 110 pcs / min ( Bottom ) 40 ~ 80 pcs / min ( T-shirt ) |
| Heater | 4.4 KW |
| Packing Speed | 5 packs / min ( max ) |
| Dimension |
L : 11000 mm W : 1900 mm H : 2700 mm |
| Film Roll Size | Ø 900 x 660 mm ( Mother Roll ) Ø 500 x 250 mm ( Outer Bag ) |
| Air Compressor | 6 HP ( not included ) |
* 規格如有變更改進，恕不另行通知。
