High Speed 2 Lines T-Shirt Bag Making Machine // Bio-Film // PLA Film

ST-77 / ST-77-500

Fully Automatic High Speed 2 Lines T-Shirt Bag Making Machine

Features



  • Suitable for the production of Bio-film and PLA film
  • 2 lines T-shirt bag making machine
  • High production efficiency to save manpower and time
  • From film roll to final bag, one process flow
  • It's easy to adjust the bag length, production speed, stacks on the interface
  • Servo motor, as standard attachment, automatic film feeding, coordination free from tension adjustment
  • Automatically stop when running out of film/ film feeding blocks or bags jam/ color scanning misses
  • Automatic error proof system


Specifications



MODEL ST-77 ST-77-500
Product Size

Length: 350 ~ 650 mm

Width: 160 ~ 360 mm

Thickness: 0.008 ~ 0.05 mm

Length: 350 ~ 900 mm

Width: 160 ~ 460 mm

Thickness: 0.008 ~ 0.05 mm

Production Speed 180 ~ 250 pcs / min / line 180 ~ 250 pcs / min / line
Upload Film Roll Size Ø 900 x 360 mm Ø 900 x 460 mm
Power 220V , 3 Phases , 50/60HZ , 15KVA 220V , 3 Phases , 50/60HZ , 15KVA
Heater 5.5 KW 6.3 KW
Dimension L x W x H 6000 x 1500 x 1750 mm 6000 x 1750 x 1750 mm
Required Air Compressor 6HP (not included) 6HP (not included)



* The specification are subject to be changed for improvement without notice.

Applications
